TC1796
System Units (Vol. 1 of 2)
General Purpose I/O Ports and Peripheral I/O Lines
User’s Manual 10-47 V2.0, 2007-07
Ports, V2.0
10.7 Port 4
This section describes the Port 4 functionality in detail.
10.7.1 Port 4 Configuration
Port 4 is a 16-bit bi-directional general-purpose I/O port that can be used for the
GPTA0/GPTA1/LTCA2 I/O lines.
Figure 10-8 Port 4 Configuration Diagram
MCA05659
P4.0 / IN24 / OUT24
P4.0
Control
P4.1
Control
P4.2
Control
P4.3
Control
P4.4
Control
P4.5
Control
P4.6
Control
P4.7
Control
P4.8
Control
P4.9
Control
P4.10
Control
P4.11
Control
P4.12
Control
P4.13
Control
P4.14
Control
P4.15
Control
GPTA1
GPTA0
LTCA2
P4.1 / IN25 / OUT25
P4.2 / IN26 / OUT26
P4.3 / IN27 / OUT27
P4.4 / IN28 / OUT28
P4.5 / IN29 / OUT29
P4.6 / IN30 / OUT30
P4.7 / IN31 / OUT31
P4.8 / IN32 / OUT32
P4.9 / IN33 / OUT33
P4.10 / IN34 / OUT34
P4.11 / IN35 / OUT35
P4.12 / IN36 / OUT36
P4.13 / IN37 / OUT37
P4.14 / IN38 / OUT38
P4.15 / IN39 / OUT39
A1
A1
A1
A1
A1
A1
A1
A1
A2
A2
A2
A2
A2
A2
A2
A2
