20.2.3 Data Registers
The Transmit Buffer Register TB contains the transmit data value. A TB write operation
latches all timing parameters stored in register SSOTC.
The Receive Buffer Register RB contains the receive data value.
TB
Transmit Buffer Register (20
H
) Reset Value: 0000 0000
H
31 16 15 0
0TB_VALUE
rrw
Field Bits Type Description
TB_VALUE [15:0] rw Transmit Data Register Value
Register TB_VALUE stores the data value to be
transmitted TB_VALUE. Unused bits of TB_VALUE
(as defined by CON.BM) are ignored during
transmission.
0 [31:16] r Reserved
Read as 0; should be written with 0.
RB
Receive Buffer Register (24
H
) Reset Value: 0000 0000
H
31 16 15 0
0RB_VALUE
rrh
Field Bits Type Description
RB_VALUE [15:0] rh Receive Data Register Value
Register RB contains the received data value
RB_VALUE. Unused bits of RB_VALUE (as defined by
CON.BM) will be not valid and should be ignored.
0 [31:16] r Reserved
Read as 0; should be written with 0.
