TC1796

System Units (Vol. 1 of 2)

CPU Subsystem

User’s Manual 2-35 V2.0, 2007-07

CPU, V2.0

2.6.4.1 DMI Register Description

The DMI Module Identification Register ID contains read-only information about the DMI

module version.

DMI_ID

DMI Module Identification Register

(F87FFC08

) Reset Value: 0008 C0XX

31 16 15 8 7 0

MODNUM MODTYPE MODREV

rrr

Field Bits Type Description

MODREV [7:0] r Module Revision Number

MODREV defines the module revision number. The value

of a module revision starts with 01

(first revision).

MODTYPE [15:8] r Module Type

This bit field defines the module as a 32-bit module: C0

MODNUM [31:16] r Module Number Value

This bit field defines the module identification number for

the DMI: 0008
