TC1796
Peripheral Units (Vol. 2 of 2)
Controller Area Network (MultiCAN) Controller
User’s Manual 22-154 V2.0, 2007-07
MultiCAN, V2.0
22.8 TTCAN Registers
All TTCAN register names described in this section are referenced by the module name
prefix “CAN_” in other parts of the TC1796 User’s Manual.
TTCAN Register Overview
Figure 22-36 TTCAN Registers
Table 22-14 TTCAN Registers
Register
Short Name
Register Long Name Offset
Address
Description
see
LTR Local Time Register 280
H
Page 22-159
SYNMR Synchronization Mark Register 284
H
Page 22-160
REFMR Reference Mark Register 288
H
Page 22-161
LREFMR Last Reference Mark Register 28C
H
Page 22-162
TURR Time Unit Ratio Register 290
H
Page 22-157
CYCTMR Cycle Time Register 294
H
Page 22-163
LOR Local Offset Register 298
H
Page 22-164
GMR Global Mark Register 29C
H
Page 22-166
LGMR Last Global Mark Register 2A0
H
Page 22-167
AWDR Application Watchdog Register 2A4
H
Page 22-168
TURR
LTR
SYNMR
MCA05862
TTCR
TTCAN Timing
Registers
TTCAN Control/
Status/Config.
Registers
TTCFGR
REFMR
LREFMR
TTSR
TTFMR
TTIRR
TTIER
TTINPR
STPTR0
TTCAN Scheduler
Registers
STSRL
CYCTMR
LOR
GMR
LGMR
AWDR
STSRH
SISR
