TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-161 V2.0, 2007-07

MultiCAN, V2.0

REFMR

Reference Mark Register (288

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

REFM

1514131211109876543210

REFMFR 0

rh r

Field Bits Type Description

REFMFR [15:9] rh Reference Mark Fraction

This bit field contains the fractional part of the

reference mark. REFMFR is the bit field

SYNMR.SYNMFR captured with the correct end of

the reference message.

REFM [31:16] rh Reference Mark

This bit field contains the integer part of the

reference mark. REFM is the bit field SYNMR.SYNM

captured with the correct end of the reference

message.

0 [8:0] r Reserved

Read as 0; should be written with 0.
