TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-160 V2.0, 2007-07

MultiCAN, V2.0

Note: If the CAN node is time master, the contents of register SYNMR are used as timing

data transferred in the reference message.

SYNMR

Synchronization Mark Register (284

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

SYNM

1514131211109876543210

SYNMFR 0

rh r

Field Bits Type Description

SYNMFR [15:9] rh Synchronization Mark Fraction

This bit field contains the fractional part of the

synchronization mark. SYNMFR is the bit field

LTR.LTFR captured with the frame synchronization

pulse.

SYNM [31:16] rh Synchronization Mark

This bit field contains the integer part of the

synchronization mark. SYNM is the bit field LTR.LT

captured with the frame synchronization pulse.

0 [8:0] r Reserved

Read as 0; should be written with 0.
