Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
CPU Subsystem
User’s Manual 2-10 V2.0, 2007-07
CPU, V2.0
2.4.1 Core Special Function Registers (CSFR)
Figure 2-6 CSFR Registers
Table 2-2 Core Special Function Registers
Register
Short Name
Register Long Name Address
MMU_CON MMU Configuration Register F7E1 8000
H
PCXI Previous Context Information Register F7E1 FE00
H
PSW Program Status Word F7E1 FE04
H
PC Program Counter F7E1 FE08
H
SYSCON System Configuration Register F7E1 FE14
H
CPU_ID CPU Identification Register F7E1 FE18
H
BIV Interrupt Vector Table Pointer F7E1 FE20
H
BTV Trap Vector Table Pointer F7E1 FE24
H
ISP Interrupt Stack Pointer F7E1 FE28
H
ICR ICU Interrupt Control Register F7E1 FE2C
H
FCX Free Context List Head Pointer F7E1 FE38
H
LCX Free Context List Limit Pointer F7E1 FE3C
H
MCA05590_mod
PC
Program State
Information
Registers
Interrupt & Trap
Control
Registers
Context
Management
Registers
FCX
LCX
Stack
Management
Registers
ICR
PSW
PCXI
System Control
Registers
SYSCON BIV
BTV
ISP
MMUCON
Identification
Register
CPU_ID
