TC1796

System Units (Vol. 1 of 2)

CPU Subsystem

User’s Manual 2-52 V2.0, 2007-07

CPU, V2.0

2.8 Floating Point Pipeline Timings

These instructions are only valid if the optional Floating Point Unit is implemented.

• Each instruction is single issued.

Table 2-18 Floating Point Instruction Timing

Instruction Result

Latency

Repeat

Rate

Instruction Result

Latency

Repeat

Rate

Floating Point Instructions

ADDF 22MSUB.F 33

CMP.F 11MUL.F 22

DIV.F 15 15 Q31TOF 22

FTOI 22QSEED.F 11

FTOQ31 22SUBF 22

FTOU 22UPDFL –1

ITOF 22UTOF 22

MADD.F 33
