TC1796

Peripheral Units (Vol. 2 of 2)

Micro Link Interface (MLI)

User’s Manual 23-114 V2.0, 2007-07

MLI, V2.0

23.4.8 Receiver Data/Address Registers

The Receiver Data Register RDATAR is a read-only register that stores data received

by a Write Frame or an Answer Frame.

RDATAR

Receiver Data Register (90

) Reset Value: 0000 0000

31 0

DATA

Field Bits Type Description

DATA [31:0] rh Data

In the receiving controller, DATA contains the data

received by a Write Frame or an Answer Frame. Bit

field RCR.DW determines the width of the relevant

data that is stored in RDATAR.

RCR.DW = 00

: RDATAR[7:0] are relevant (8-bit)

RCR.DW = 01

: RDATAR[15:0] are relevant (16-bit)

RCR.DW = 10

: RDATAR[31:0] are relevant (32-bit)
