TC1796
Peripheral Units (Vol. 2 of 2)
Micro Link Interface (MLI)
User’s Manual 23-113 V2.0, 2007-07
MLI, V2.0
The Receiver Pipe x Status Register RPxSTATR indicates the coded buffer size which
represents the Remote Window Size of 2 Bytes to 64KBytes and the address prediction
factor that has been calculated for pipe x in the receiving controller.
0 [23:21],
[31:25]
r Reserved
Read as 0; should be written with 0.
RPxSTATR (x = 0-3)
Receiver Pipe x Status Register (7C
H
+4
H
*x) Reset Value: 0000 0000
H
31 16 15 6 5 4 3 0
0AP0BS
rrhrrh
Field Bits Type Description
BS [3:0] rh Buffer Size
This bit field indicates the size of pipe x Remote Window
in the receiving controller. It is updated by hardware
when a Copy Base Address Frame has been received
(see Page 23-26).
0000
B
1-bit offset address of Remote Window
0001
B
2-bit offset address of Remote Window
0010
B
3-bit offset address of Remote Window
…
B
…
1110
B
15-bit offset address of Remote Window
1111
B
16-bit offset address of Remote Window
AP [15:6] rh Address Prediction Factor
AP contains the address prediction factor that has been
calculated for pipe x in the receiving controller. It is a
signed 9-bit number with the sign in its most significant
bit (see Page 23-45).
0 [5:4],
[31:16]
r Reserved
Read as 0.
Field Bits Type Description
