TC1796

Peripheral Units (Vol. 2 of 2)

Asynchronous/Synchronous Serial Interface (ASC)

User’s Manual 19-8 V2.0, 2007-07

ASC, V2.0

Note: In wake-up mode, received frames are transferred to the receive buffer register

only if the 9

bit (the wake-up bit) is 1. If this bit is 0, no receive interrupt request

will be activated and no data will be transferred.

19.1.3.4 RXD/TXD Data Path Selection in Asynchronous Modes

The data paths for the serial input and output data in Asynchronous Modes are affected

by control bit CON.LB (loop-back) as shown in Figure 19-5.

Figure 19-5 RXD/TXD Data Path Selection in Asynchronous Modes

MCA05766

ASC

Asynch. Mode Logic

RXD

CON

TXD
