TC1796
System Units (Vol. 1 of 2)
LMB External Bus Unit
User’s Manual 13-79 V2.0, 2007-07
EBU, V2.0
13.10 EBU Registers
This section describes the registers and programmable parameters of the EBU.
Figure 13-31 shows all registers associated with the EBU. All these registers can be
read in User Mode, but can only be written in Supervisor Mode.
EBU Registers Overview
Figure 13-31 EBU Registers
The complete and detailed address map of the PMU module with its registers is shown
in Table 18-34 on Page 18-112 of this TC1796 System Units (Vol. 1 of 2) User’s Manual.
Table 13-21 Registers Address Space -Flash Registers
Module Base Address End Address Note
EBU F800 0000
H
F800 03FF
H
–
Table 13-22 Registers OverviewPMU Overlay Control Registers
Register
Short Name
Register Long Name Offset
Address
Description
see
EBU_CLC EBU Clock Control Register 000
H
Page 13-82
EBU_ID EBU Module Identification Register 008
H
Page 13-81
EBU_CON EBU Configuration Register 010
H
Page 13-83
EBU_BFCON EBU Burst Flash Control Register 020
H
Page 13-86
MCA05741_mod
EBU_CLC EBU_EMUAS
Control / Status /
Test Registers
Emulator
Registers
EBU_CON
EBU_EMUBC
EBU_EMUBAP
EBU_BFCON
EBU_ADDRSELx
EBU_BUSCONx
EBU_BUSAPx
EBU_EMUOVL
EBU_USERCON
x = 3-0
EBU_ID
To Next Page
