TC1796

System Units (Vol. 1 of 2)

LMB External Bus Unit

User’s Manual 13-111 V2.0, 2007-07

EBU, V2.0

13.10.12 Test/Control Configuration Register, USERCON

EBU_USERCON

EBU Test/Control Configuration Register

(190

) Reset Value: 0000 0000

31 10

rrw

Field Bits Type Description

DIP 0rwDisable Internal Pipelining

The EBU can accept a new LMB transaction

before the previous LMB transaction has been

completed.

The EBU will issue an LMB re-try if an LMB

access is received while a previous LMB

transaction is still not completed.

0 [31:1] r Reserved

Read as 0; should be written with 0.
