TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-152 V2.0, 2007-07

MultiCAN, V2.0

22.7.8 TTCAN Interrupt Control

Figure 22-34 and Figure 22-35 show the configurations of the three TTCAN interrupts.

Figure 22-34 New Basic Cycle and Notification Interrupt Structure

MCA05860

NBCINP

NBC

New Matrix Cycle

New Basic Cycle

New Basic

Cycle Interrupt

TTIRR

TTINPR

NMC NBCIE

TTIER

State Change

TTSR

WFE DISC

SYNCSC MSRC ERRSC

TTIRR

Last Reference Message

indicates next-is-Gap

TTIRR

Last Reference Message

indicates Discontinuity

NOTIFIE

ERRSCIEMSRCIESYNCSCIE

TTIER

NOTIFINP

TTINPR

Notification

Interrupt

≥1

State Change

ERRS

MSR

SYNCS
