TC1796

System Units (Vol. 1 of 2)

CPU Subsystem

User’s Manual 2-15 V2.0, 2007-07

CPU, V2.0

2.4.3 CPU General Purpose Registers

Figure 2-8 GPR Registers

Table 2-4 GPR Registers

Name

D0 Data Register 0 F7E1 FF00

D1 Data Register 1 F7E1 FF04

D2 Data Register 2 F7E1 FF08

D3 Data Register 3 F7E1 FF0C

D4 Data Register 4 F7E1 FF10

D5 Data Register 5 F7E1 FF14

D6 Data Register 6 F7E1 FF18

D7 Data Register 7 F7E1 FF1C

D8 Data Register 8 F7E1 FF20

D9 Data Register 9 F7E1 FF24

D10 Data Register 10 F7E1 FF28

MCA05592

A15 (implicit address) D15 (implicit data)

Address General

Purpose Registers

(AGPR)

Data General

Purpose

Registers (DGPR)

A14 D14

D13

D12

D11

D10

E14

E12

E10

64-Bit Extended

Data Registers

A13

A12

A11 (return address)

A10 (stack pointer)

A9 (global address)

A8 (global address)

A1 (global address)

A0 (global address)
