TC1796
System Units (Vol. 1 of 2)
CPU Subsystem
User’s Manual 2-16 V2.0, 2007-07
CPU, V2.0
D11 Data Register 11 F7E1 FF2C
H
D12 Data Register 12 F7E1 FF30
H
D13 Data Register 13 F7E1 FF34
H
D14 Data Register 14 F7E1 FF38
H
D15 Data Register 15 F7E1 FF3C
H
A0 Address Register 0 (Global Address Register) F7E1 FF80
H
A1 Address Register 1 (Global Address Register) F7E1 FF84
H
A2 Address Register 2 F7E1 FF88
H
A3 Address Register 3 F7E1 FF8C
H
A4 Address Register 4 F7E1 FF90
H
A5 Address Register 5 F7E1 FF94
H
A6 Address Register 6 F7E1 FF98
H
A7 Address Register 7 F7E1 FF9C
H
A8 Address Register 8 (Global Address Register) F7E1 FFA0
H
A9 Address Register 9 (Global Address Register) F7E1 FFA4
H
A10 Address Register 10 (Stack Pointer) F7E1 FFA8
H
A11 Address Register 11 (Return Address) F7E1 FFAC
H
A12 Address Register 12 F7E1 FFB0
H
A13 Address Register 13 F7E1 FFB4
H
A14 Address Register 14 F7E1 FFB8
H
A15 Address Register 15 F7E1 FFBC
H
Table 2-4 GPR Registers (cont’d)
Register Short
Name
Register Long Name Address
