TC1796
Peripheral Units (Vol. 2 of 2)
Controller Area Network (MultiCAN) Controller
User’s Manual 22-209 V2.0, 2007-07
MultiCAN, V2.0
22.9.4.5 External CAN Time Trigger Inputs
The external CAN time trigger inputs ECTT[7:1] can be used as a transmit trigger for a
reference message. In the TC1796, these input lines are connected as shown in
Table 22-20.
22.9.4.6 DMA Request Outputs
The interrupt output lines INT_O0 to INT_O2 of the MultiCAN module can be used as a
DMA requestor and are able to trigger DMA transfers. INT_O[2:0] are connected to the
DMA controller as shown in Table 22-21.
Table 22-20 External CAN Time Trigger Inputs
Receive Input Connected to From Module
ECTT1 P1.3 / REQ3 Input Port 1
ECTT2 P7.5 / REQ7 Input Port 7
ECTT3 Output OUT5 GPTA0
ECTT4 Output IOUT2 External Request Unit (SCU)
ECTT5 Output IOUT3 External Request Unit (SCU)
ECTT6 0 –
ECTT7 0 –
Table 22-21 CAN-to-DMA Request Connections
DMA Channel Connected to
CAN Interrupt Output
Selected in DMA Controller
by Programming
04 INT_O0 CHCR04.PRSEL = 101
B
05 INT_O0 CHCR05.PRSEL = 101
B
06 INT_O1 CHCR06.PRSEL = 110
B
07 INT_O2 CHCR07.PRSEL = 110
B
15 INT_O3 CHCR15.PRSEL = 101
B
