TC1796

Peripheral Units (Vol. 2 of 2)

Analog-to-Digital Converter (ADC)

User’s Manual 25-59 V2.0, 2007-07

ADC, V2.0

25.2.1 Identification Register

Note: In TC1796 only ADC0_ID is available. There is no ADC1_ID register available.

ADC0_ID

ADC0 Module Identification Register (008

) Reset Value: 0030 C0XX

31 16 15 8 7 0

MODNUM MODTYPE MODREV

rrr

Field Bits Type Description

MODREV [7:0] r Module Revision Number

MODREV defines the module revision number. The value

of a module revision starts with 01

(first revision).

MODTYPE [15:8] r Module Type

This bit field defines the module as a 32-bit module: C0

MODNUM [31:16] r Module Number Value

This bit field defines the module identification number for

the ADC: 0030
