TC1796

System Units (Vol. 1 of 2)

LMB External Bus Unit

User’s Manual 13-81 V2.0, 2007-07

EBU, V2.0

13.10.1 Identification Register, ID

The Module Identification Register ID contains read-only information about the EBU

module version.

EBU_ID

EBU Module Identification Register (008

) Reset Value: 0014 C0XX

31 16 15 8 7 0

MODNUM MODTYPE MODREV

rrr

Field Bits Type Description

MODREV [7:0] r Module Revision Number

MODREV defines the module revision number. The value

of a module revision starts with 01

(first revision).

MODTYPE [15:8] r Module Type

This bit field defines the module as a 32-bit module: C0

MODNUM [31:16] r Module Number Value

This bit field defines the module identification number for

the EBU: 0014
