TC1796
System Units (Vol. 1 of 2)
General Purpose I/O Ports and Peripheral I/O Lines
User’s Manual 10-33 V2.0, 2007-07
Ports, V2.0
10.5.2 Port 2 Function Table
Table 10-11 summarizes the I/O control selection functions of each Port 2 line.
Table 10-11 Port 2 Functions
Port
Pin
I/O Pin Functionality Associated Reg./
I/O Line
Port I/O Control Select.
Reg./Bit Field Value
P2.2 I General-purpose input P2_IN.P2 P2_IOCR0.PC2 0XXX
B
O General-purpose output P2_OUT.P2 1X00
B
SSC0 output SLSO02 1X01
B
SSC1 output SLSO12 1X10
B
SSC0/SSC1 output SLSO02 AND
SLSO12
1X11
B
P2.3 I General-purpose input P2_IN.P3 P2_IOCR0.PC3 0XXX
B
O General-purpose output P2_OUT.P3 1X00
B
SSC0 output SLSO03 1X01
B
SSC1 output SLSO13 1X10
B
SSC0/SSC1 output SLSO03 AND
SLSO13
1X11
B
P2.4 I General-purpose input P2_IN.P4 P2_IOCR4.PC4 0XXX
B
O General-purpose output P2_OUT.P4 1X00
B
SSC0 output SLSO04 1X01
B
SSC1 output SLSO14 1X10
B
SSC0/SSC1 output SLSO04 AND
SLSO14
1X11
B
P2.5 I General-purpose input P2_IN.P5 P2_IOCR4.PC5 0XXX
B
O General-purpose output P2_OUT.P5 1X00
B
SSC0 output SLSO05 1X01
B
SSC1 output SLSO15 1X10
B
SSC0/SSC1 output SLSO05 AND
SLSO15
1X11
B
