12.4.2.1 Memory Checker Registers

The MCHK Module Identification Register ID contains read-only information about the

MCHK module version.

MCHK_ID

Memory Checker Module Identification Register

(008

) Reset Value: 001B C0XX

31 16 15 8 7 0

MODNUM MODTYPE MODREV

rrr

Field Bits Type Description

MODREV [7:0] r Module Revision Number

MODREV defines the module revision number. The value

of a module revision starts with 01

(first revision).

MODTYPE [15:8] r Module Type

This bit field defines the module as a 32-bit module: C0

MODNUM [31:16] r Module Number Value

This bit field defines the module identification number for

the MCHK: 001B
