TC1796
Peripheral Units (Vol. 2 of 2)
Micro Link Interface (MLI)
User’s Manual 23-115 V2.0, 2007-07
MLI, V2.0
The Receiver Pipe x Base Address Register RPxBAR is a read-only register that
contains the complete target address in the Remote Window of pipe x.
RPxBAR (x = 0-3)
Receiver Pipe x Base Address Register
(6C
H
+4
H
*x) Reset Value: 0000 0000
H
31 0
ADDR
rh
Field Bits Type Description
ADDR [31:0] rh Address
ADDR indicates the complete target address for the
pipe x Remote Window.
When a pipe x Copy Base Address Frame is received,
ADDR[31:4] becomes loaded with the transmitted 28-bit
address and bits [3:0] are cleared.
When a write or Read Frame with m bits of address
offset is received, bits ADDR[31:m] are held constant
and bits ADDR[m-1:0] are replaced by the received
offset.
When an optimized read or data frame is received, the
address prediction mechanism adds the predicted
address offset RPxSTATR.AP to ADDR and stores the
result in ADDR.
When an Answer Frame is received, ADDR is not
changed.
