TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-159 V2.0, 2007-07

MultiCAN, V2.0

LTR

Local Time Register (280

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

1514131211109876543210

LTFR 0

rh r

Field Bits Type Description

LTFR [15:6] rh Local Time Fraction

This bit field contains the fractional part of the NTU

counter (TTCAN level 2 only). In the case of an

overflow after the addition of the TUR value, the

value of LT is incremented by one.

LT [31:16] rh Local Time

This bit field contains the integer part of the NTU

counter. In TTCAN level 1, it is incremented with

each CAN bit time, in level 2 it is incremented each

time the fractional part LTFR has an overflow.

0 [5:0] r Reserved

Read as 0; should be written with 0.
