TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-162 V2.0, 2007-07

MultiCAN, V2.0

LREFMR

Last Reference Mark Register (28C

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

LREFM

1514131211109876543210

LREFMFR 0

rh r

Field Bits Type Description

LREFMFR [15:9] rh Last Reference Mark Fraction

This bit field contains the fractional part of the last

reference mark. LREFMFR is the bit field

REFMR.REFMFR captured with the correct end of

the reference message.

LREFM [31:16] rh Last Reference Mark

This bit field contains the integer part of the last

reference mark. LREFM is the bit field

REFMR.REFM captured with the correct end of the

reference message.

0 [8:0] r Reserved

Read as 0; should be written with 0.
