TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-167 V2.0, 2007-07

MultiCAN, V2.0

Note: The difference between the actual global mark and the last one can be used to

determine the value required for the TURR.TUR update (not for the actual time

master).

LGMR

Last Global Mark Register (2A0

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

LGM

1514131211109876543210

LGMFR 0

rh r

Field Bits Type Description

LGMFR [15:9] rh Last Global Mark Fraction

This bit field contains the value of GMFR of the last

reference mark.

LGM [31:16] rh Last Global Mark

This bit field contains the value of GM of the last

reference mark.

0 [8:0] r Reserved

Read as 0; should be written with 0.
