TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-166 V2.0, 2007-07

MultiCAN, V2.0

GMR

Global Mark Register (29C

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

1514131211109876543210

GMFR 0

rh r

Field Bits Type Description

GMFR [15:9] rh Global Mark Fraction

This bit field contains the fractional part of the global

mark.

GM [31:16] rh Global Mark

This bit field contains the integer part of the global

mark.

Time master (transmitting reference messages):

The sum of the local offset and the local time is

stored as global time (Global_Sync_Mark) in register

GMR at the beginning of the reference message.

Not time master (receiving reference messages):

The global time information in GMR is received as

Global_Ref_Mark by reference message.

0 [8:0] r Reserved

Read as 0; should be written with 0.
