TC1796

System Units (Vol. 1 of 2)

User’s Manual 18-84 V2.0, 2007-07

Regs, V2.0

Table 18-28 Address Map of FADC

Short Name Description Address Access Mode Reset Value

Read Write

Fast Analog-to-Digital Converter (FADC)

FADC_CLC FADC Clock Control

F010 0300

U, SV SV, E 0000 0003

– Reserved F010 0304

BE BE –

FADC_ID FADC Module

Identification Register

F010 0308

U, SV nBE 0027 C0XX

FADC_FDR FADC Fractional Divider

F010 030C

U, SV SV, E 0000 0000

FADC_

CRSR

FADC Conversion

Request Status Register

F010 0310

U, SV U, SV 0000 0000

FADC_FMR FADC Flag Modification

F010 0314

U, SV U, SV 0000 0000

FADC_

NCTR

FADC Neighbor Channel

Trigger Register

F010 0318

U, SV U, SV 0000 0000

FADC_GCR FADC Global Control

F010 031C

U, SV U, SV 0000 0000

FADC_

CFGR0

FADC Channel 0

Configuration Register

F010 0320

U, SV U, SV 0000 0000

FADC_

CFGR1

FADC Channel 1

Configuration Register

F010 0324

U, SV U, SV 0000 0000

FADC_

CFGR2

FADC Channel 2

Configuration Register

F010 0328

U, SV U, SV 0000 0000

FADC_

CFGR3

FADC Channel 3

Configuration Register

F010 032C

U, SV U, SV 0000 0000

FADC_

ACR0

FADC Channel 0 Analog

Control Register

F010 0330

U, SV U, SV 0000 0000

FADC_

ACR1

FADC Channel 1 Analog

Control Register

F010 0334

U, SV U, SV 0000 0000

FADC_

ACR2

FADC Channel 2 Analog

Control Register

F010 0338

U, SV U, SV 0000 0000

FADC_

ACR3

FADC Channel 3 Analog

Control Register

F010 033C

U, SV U, SV 0000 0000
