Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-92 V2.0, 2007-07
Regs, V2.0
Analog-to-Digital Converter 1 (ADC1)
– Reserved F010 0600
H
nBE nBE –
– Reserved F010 0604
H
BE BE –
– Reserved F010 0608
H
BE BE –
– Reserved F010 060C
H
nBE nBE –
ADC1_
CHCON0
ADC1 Channel Control
Register 0
F010 0610
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON1
ADC1 Channel Control
Register 1
F010 0614
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON2
ADC1 Channel Control
Register 2
F010 0618
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON3
ADC1 Channel Control
Register 3
F010 061C
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON4
ADC1 Channel Control
Register 4
F010 0620
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON5
ADC1 Channel Control
Register 5
F010 0624
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON6
ADC1 Channel Control
Register 6
F010 0628
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON7
ADC1 Channel Control
Register 7
F010 062C
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON8
ADC1 Channel Control
Register 8
F010 0630
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON9
ADC1 Channel Control
Register 9
F010 0634
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON10
ADC1 Channel Control
Register 10
F010 0638
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON11
ADC1 Channel Control
Register 11
F010 063C
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON12
ADC1 Channel Control
Register 12
F010 0640
H
U, SV U, SV 0000 0000
H
ADC1_
CHCON13
ADC1 Channel Control
Register 13
F010 0644
H
U, SV U, SV 0000 0000
H
Table 18-29 Address Map of ADC0/ADC1 (cont’d)
Short Name Description Address Access Mode Reset Value
Read Write
