Infineon Technologies TC1796 User Manual

TC1796
System Units (Vol. 1 of 2)
Register Overview
User’s Manual 18-95 V2.0, 2007-07
Regs, V2.0
ADC1_
CHSTAT11
ADC1 Channel Status
Register 11
F010 075C
H
U, SV U, SV 0000 0000
H
ADC1_
CHSTAT12
ADC1 Channel Status
Register 12
F010 0760
H
U, SV U, SV 0000 0000
H
ADC1_
CHSTAT13
ADC1 Channel Status
Register 13
F010 0764
H
U, SV U, SV 0000 0000
H
ADC1_
CHSTAT14
ADC1 Channel Status
Register 14
F010 0768
H
U, SV U, SV 0000 0000
H
ADC1_
CHSTAT15
ADC1 Channel Status
Register 15
F010 076C
H
U, SV U, SV 0000 0000
H
ADC1_
QUEUE0
ADC1 Queue Status
Register
F010 0770
H
U, SV U, SV 0000 0000
H
– Reserved F010 0774
H
-
F010 077C
H
BE BE –
ADC1_
SW0CRP
ADC1 Software SW0
Conversion Request
Pending Register
F010 0780
H
U, SV U, SV 0000 0000
H
– Reserved F010 0784
H
BE BE –
ADC1_
ASCRP
ADC1 Auto Scan
Conversion Request
Pending Register
F010 0788
H
U, SV U, SV 0000 0000
H
– Reserved F010 078C
H
BE BE –
ADC1_
SYSTAT
ADC1 Synchronization
Status Register
F010 0790
H
U, SV U, SV 0000 0000
H
– Reserved F010 0794
H
-
F010 079C
H
BE BE –
– Reserved; these locations
must not be written.
F010 07A0
H
-
F010 07A4
H
nBE nBE –
– Reserved F010 07A8
H
-
F010 07AC
H
BE BE –
ADC1_
TSTAT
ADC1 Timer Status
Register
F010 07B0
H
U, SV U, SV 0000 0000
H
Table 18-29 Address Map of ADC0/ADC1 (cont’d)
Short Name Description Address Access Mode Reset Value
Read Write
