TC1796

Peripheral Units (Vol. 2 of 2)

Asynchronous/Synchronous Serial Interface (ASC)

User’s Manual 19-29 V2.0, 2007-07

ASC, V2.0

The Receive Buffer Register RBUF of the ASC module contains the receive data value

in Asynchronous Mode and Synchronous Mode.

RBUF

Receive Buffer Register (24

) Reset Value: 0000 0000

31 9 8 0

0RD_VALUE

rrh

Field Bits Type Description

RD_VALUE [8:0] rh Receive Data Register Value

RBUF contains the received data bits and, depending

on the selected mode, the parity bit in the

asynchronous and synchronous operating modes of

the ASC.

In Asynchronous Mode, with CON.M = 011

(7-bit

data + parity), the received parity bit is written into

RBUF.7.

In Asynchronous Mode, with CON.M = 111

(8-bit

data + parity), the received parity bit is written into

RBUF.8.

0 [31:9] r Reserved

Read as 0.
