Synchronous Serial Interface (SSC)
User’s Manual 20-55 V2.0, 2007-07
SSC, V2.1
Input/Output Control Registers
P2_IOCR0
Port 2 Input/Output Control Register 0(10
H
) Reset Value: 2020 2020
H
31 28 23 20 15 12 7 4 0
PC3 0PC20 0010 0 0010 0
rw rrwr rw r rw r
Field Bits Type Description
PC2,
PC3
[23:20],
[31:28]
rw Port Output Control for Port 2.2 and P2.3
1)
These bit fields determine the output port
functionality:
Port input/output control for P2.2/SLSO2
Port input/output control for P2.3/SLSO3
1) Coding of bit field see Table 20-5. Shaded bits and bit fields are “don’t care” for SSC I/O port control.
P2_IOCR4
Port 2 Input/Output Control Register 4(14
H
) Reset Value: 2020 2020
H
31 28 23 20 15 12 7 4 0
PC7 0PC60PC50PC40
rw rrwrrwrrwr
Field Bits Type Description
PC4,
PC5,
PC6,
PC7
[7:4],
[15:12],
[23:20],
[31:28]
rw Port Output Control for Port 2.[7:4]
1)
These bit fields determine the output port
functionality:
Port input/output control for P2.4/SLSO4
Port input/output control for P2.5/SLSO5
Port input/output control for P2.6/SLSO6
Port input/output control for P2.7/SLSO7
1) Coding of bit field see Table 20-5. Shaded bits and bit fields are “don’t care” for SSC I/O port control.
