TC1796

Peripheral Units (Vol. 2 of 2)

Micro Second Channel (MSC)

User’s Manual 21-69 V2.0, 2007-07

MSC, V2.0

Note: Further details of the fractional divider register functionality are described in

section “Fractional Divider Operation” on Page 3-29 of the TC1796 User’s

Manual System Units part (Volume 1).

ENHW 30 rw Enable Hardware Clock Control

Controls operation of ECEN input and DISCLK bit.

DISCLK 31 rwh Disable Clock

Hardware controlled disable for f

OUT

signal.

0 10,

[27:26]

rw Reserved

Read as 0; should be written with 0.

Field Bits Type Description

Table of Contents9
