TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-52 V2.0, 2007-07

MultiCAN, V2.0

generated whenever the CUR pointer reaches the value of the SEL pointer. Thus SEL

makes it possible to detect the end of a predefined message transfer series or to issue

a warning interrupt when the FIFO becomes full.

Figure 22-21 FIFO Structure with FIFO Base Object and n FIFO Slave Objects

MCA05847

Slave Object fi

PPREV = f[i-1]

PNEXT = f[i+1]

Slave Object fn

PPREV = f[n-1]

PNEXT

Slave Object f2

PPREV = f1

PNEXT = f3

Slave Object f1

PPREV

PNEXT = f2

Base Object

PPREV

PNEXT

TOP = fn

CUR = fi

BOT = f1
