TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-82 V2.0, 2007-07

MultiCAN, V2.0

TRINP [11:8] rw Transfer OK Interrupt Node Pointer

TRINP selects the interrupt output line INT_Om

(m = 0-15) for a transfer OK interrupt of CAN Node x.

0000

Interrupt output line INT_O0 is selected.

0001

Interrupt output line INT_O1 is selected.

…

1110

Interrupt output line INT_O14 is selected.

1111

Interrupt output line INT_O15 is selected.

CFCINP [15:12] rw Frame Counter Interrupt Node Pointer

CFCINP selects the interrupt output line INT_Om

(m = 0-15) for a frame counter overflow interrupt of

CAN Node x.

0000

Interrupt output line INT_O0 is selected.

0001

Interrupt output line INT_O1 is selected.

…

1110

Interrupt output line INT_O14 is selected.

1111

Interrupt output line INT_O15 is selected.

0 [31:16] r Reserved

Read as 0; should be written with 0.

Field Bits Type Description
