TC1796

Peripheral Units (Vol. 2 of 2)

Controller Area Network (MultiCAN) Controller

User’s Manual 22-109 V2.0, 2007-07

MultiCAN, V2.0

Message Object n Arbitration Register MOARn contains the CAN identifier of message

object n.

MOARn (n = 0-127)

Message Object n Arbitration Register

(0618

+n*20

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

PRI IDE ID

rw rwh rwh

1514131211109876543210

rwh

Field Bits Type Description

ID [28:0] rwh CAN Identifier of Message Object n

Identifier of a standard message (ID[28:18]) or an

extended message (ID[28:0]). For standard

identifiers, bits ID[17:0] are “don’t care”.

IDE 29 rwh Identifier Extension Bit of Message Object n

Message object n handles standard frames

with 11-bit identifier.

Message object n handles extended frames

with 29-bit identifier.
