TC1796
Peripheral Units (Vol. 2 of 2)
Controller Area Network (MultiCAN) Controller
User’s Manual 22-177 V2.0, 2007-07
MultiCAN, V2.0
CFGM 12 rh Configuration Mode Flag
This bit indicates whether or not Configuration Mode
is active.
0
B
The TTCAN node is not in Configuration
Mode.
1
B
The TTCAN node is in Configuration Mode. It
will not transmit messages and it will not
update the MSC bit fields.
TMPC 13 rh Time Master Priority Conflict
This bit indicates if there is a priority conflict between
the current time master and this TTCAN node. A
priority conflict occurs if the current time master has
a lower priority than the TTCAN node itself (potential
time master).
0
B
A priority conflict has not been detected for the
last reference message.
1
B
The TTCAN node is a potential time master
with a priority conflict (the last reference
message has been received with a lower
priority than TTCR.TMPRIO).
TRAF 14 rh Transmission Finished Flag
This bit is set when the CAN node correctly
terminates a transmission of a message. It is cleared
when the next time mark is reached.
This flag is used for the interrupt generation of the
time mark entries and the interrupt entries.
0
B
Since the last time mark has been reached,
the CAN node has not yet correctly terminated
a transmission.
1
B
Since the last time mark has been reached,
the CAN node has correctly terminated a
transmission.
Field Bits Type Description
