ERRSC 8rwhError State Change
This bit indicates that the bit field TTSR.ERRS has
changed.
0
B
TTSR.ERRS has not changed.
1
B
TTSR.ERRS has changed.
MSRC 9rwhMaster-Slave Relation Change
This bit indicates that the bit field MSR has changed.
0
B
TTSR.MSR has not changed.
1
B
TTSR.MSR has changed.
SYNCSC 10 rwh Synchronization State Change
This bit indicates that the bit field TTSR.SYNCS has
changed.
0
B
TTSR.SYNCS has not changed.
1
B
TTSR.SYNCS has changed.
EOS 11 rwh End Of Scheduler Entry Flag
This bit is set when the TTCAN scheduler reads an
EOS entry. In this case, bit TTSR.CFGM is
automatically set.
0
B
The TTCAN scheduler has not yet read an
EOS entry.
1
B
The TTCAN scheduler has read an EOS entry.
WFE 12 rwh Wait For Event Flag
This bit is set when a reference message is received
indicating a next-is-gap (not for the current time
master). This event can generate a notification
interrupt.
0
B
The last reference message received was not
indicating next-is-gap.
1
B
The last reference message received was
indicating next-is-gap.
DISC 13 rwh Discontinuity Flag
This bit is set when a reference message is received
indicating a discontinuity (not for the current time
master). This event can generate a notification
interrupt.
0
B
The last reference message received was not
indicating a discontinuity.
1
B
The last reference message received was
indicating a discontinuity.
