Infineon Technologies TC1796 User Manual

TC1796
Peripheral Units (Vol. 2 of 2)
Controller Area Network (MultiCAN) Controller
User’s Manual 22-191 V2.0, 2007-07
MultiCAN, V2.0
NBCINP [7:4] rw New Basic Cycle Interrupt Node Pointer
NBCINP selects the interrupt output line INT_Om
(m = 0-15) for a new basic or matrix cycle interrupt.
This interrupt can be generated only when the
reference message is received. The interrupt for
transmitted reference messages is controlled by the
reference message entry in the scheduler.
0000
B
Interrupt output line INT_O0 is selected.
0001
B
Interrupt output line INT_O1 is selected.
…
B
…
1110
B
Interrupt output line INT_O14 is selected.
1111
B
Interrupt output line INT_O15 is selected.
NOTIFINP [11:8] rw Notification Interrupt Node Pointer
NOTIFINP selects the interrupt output line INT_Om
(m = 0-15) for a notification interrupt. Possible
notification events for this interrupt node pointer are:
• bit field TTSR.ERRS changes
• bit field TTSR.MSR changes
• bit field TTSR.SYNCS changes
• bit TTIRR.WFE is set
• bit TTIRR.DISC is set
0000
B
Interrupt output line INT_O0 is selected.
0001
B
Interrupt output line INT_O1 is selected.
…
B
…
1110
B
Interrupt output line INT_O14 is selected.
1111
B
Interrupt output line INT_O15 is selected.
0 [31:12] r Reserved
Read as 0; should be written with 0.
Field Bits Type Description
