TC1796

Peripheral Units (Vol. 2 of 2)

General Purpose Timer Array (GPTA)

User’s Manual 24-138 V2.0, 2007-07

GPTA, V2.0

Timer()

if ( (LTCk.X == 0xFFFF) and (LTCk.X_Write_Access) ) then

//above condition is also true for timer overflow or software reset

trig(LTCk.Service_Request_Trigger)

LTCk.Event = 1

else

LTCk.Event = 0

endif

if (LTCk.Signal_Input) then

if (LTCk.Reset_Timer_Bit) then //timer must be reset

LTCk.Reset_Timer_Bit = 0

LTCk.X = 0xFFFF

if (LTCk.Coherent_Update_Enable) then

LTCk.Select_Line_Value = !LTCk.Select_Line_Value

LTCk.Coherent_Update_Enable = 0

endif

else //timer runs normally

LTCk.X ++

endif

LTCk.Event_Out = LTCk.Event
