TC1796
Peripheral Units (Vol. 2 of 2)
General Purpose Timer Array (GPTA)
User’s Manual 24-142 V2.0, 2007-07
GPTA, V2.0
Variables
Input, Local, Output variables of the cell (I, L, O)
Name Short
Name
(*)LTC
Used
(ILO)
Comment
LTCk.Data_In *DINkp I Data input from input multiplexer
LTCk.Y_In *YIk I Timer coming from preceding cell
LTCk.Output_Mode_In *M1Ik
*M0Ik
I Link signals coming from preceding
cell
LTCk.Timer_Event_In *TIk I Signal for timer change from
preceding cell
LTCk.Event_In *EIk I Signal for event from following cell
LTCk.Select_In *SI I Select signal from preceding cell
LTCk.X_Write_Access *XWA L Indicates that LTCk.X was modified
LTCk.Select_Line_Value *SLV L Internal value for select line
reset value: 0
LTCk.Signal_Input *INS L Qualified input signal for Timer
Mode and Capture Mode
LTCk.Reset_Timer_Bit *RTM L Flipflop to reset timer on next clock
LTCk.Event *EVE L Local event
LTCk.Data_Out *DOUk O Data output for output multiplexer
LTCk.Service_Request_Trigger *SQTk O Service request line
LTCk.Y_Out *YOk O Timer going to following cell
LTCk.Output_Mode_Out *M1Ok
*M0Ok
O Link signals to following cell
LTCk.Timer_Event_Out *TOk O Event output to following cell
LTCk.Select_Out *SO O Select output to following cell
LTCk.Event_Out *EOk O Event output to preceding cell
