TC1796

Peripheral Units (Vol. 2 of 2)

General Purpose Timer Array (GPTA)

User’s Manual 24-171 V2.0, 2007-07

GPTA, V2.0

REN 7rwInterrupt Request Enable

The interrupt request is disabled

An interrupt request is generated when timer GTk

overflows

0 [31:8] r Reserved

Read as 0; should be written with 0.

GPTA0_GTTIMk (k = 0-1)

GPTA0 Global Timer Register k (0E8

+k*10

) Reset Value: 0000 0000

GPTA1_GTTIMk (k = 0-1)

GPTA1 Global Timer Register k (0E8

+k*10

) Reset Value: 0000 0000

31 24 23 0

0TIM

rrwh

Field Bits Type Description

TIM [23:0] rwh Timer Value of Global Timer k

0 [31:24] r Reserved

Read as 0; should be written with 0.

Field Bits Type Description
