TC1796

Peripheral Units (Vol. 2 of 2)

General Purpose Timer Array (GPTA)

User’s Manual 24-190 V2.0, 2007-07

GPTA, V2.0

LTCXRk (k = 00-62)

Local Timer Cell X Register k (204

+k*8

) Reset Value: 0000 0000

31 16 15 0

rrwh

Field Bits Type Description

X [15:0] rwh Local Timer Data Register Value

0 [31:16] r Reserved

Read as 0; should be written with 0.

LTCXR63

Local Timer Cell X Register 63 (3FC

) Reset Value: 0000 0000

31 16 15 0

XS X

rw rwh

Field Bits Type Description

X [15:0] rwh Compare Register Value

XS [31:16] rw Shadow Register Value
