TC1796
Peripheral Units (Vol. 2 of 2)
General Purpose Timer Array (GPTA)
User’s Manual 24-220 V2.0, 2007-07
GPTA, V2.0
Table 24-18 Group to I/O Line/Cell Assignment
Group/Module Cell/Line Input Output
LTC Groups
LTCG0 LTC[07:00] LTC[07:00]IN LTC[07:00]OUT
LTCG1 LTC[15:08] LTC[15:08]IN LTC[15:08]OUT
LTCG2 LTC[23:16] LTC[23:16]IN LTC[23:16]OUT
LTCG3 LTC[31:24] LTC[31:24]IN LTC[31:24]OUT
LTCG4 LTC[39:32] LTC[39:32]IN LTC[39:32]OUT
LTCG5 LTC[47:40] LTC[47:40]IN LTC[47:40]OUT
LTCG6 LTC[55:48] LTC[55:48]IN LTC[55:48]OUT
LTCG7 LTC[63:56] LTC[63:56]IN LTC[63:56]OUT
I/O Groups
IOG0 – IN[07:00] OUT[07:00]
IOG1 – IN[15:08] OUT[15:08]
IOG2 – IN[23:16] OUT[23:16]
IOG3 – IN[31:24] OUT[31:24]
IOG4 – IN[39:32] OUT[39:32]
Output Groups
OG0 – – OUT[63:56]
OG1 – – OUT[71:64]
OG2 – – OUT[79:72]
OG3 – – OUT[87:80]
OG4 – – OUT[95:88]
OG5 – – OUT[103:96]
OG6 – – OUT[111:104]
Clock Group
– – CLK[7:0] CLK[7:0]
PDL/INT Groups
PDL[1:0] PDL Bus – PDL[3:0] PDL[3:0]
External Input [3:0] – INT[3:0] INT[3:0]
To Next Page
