TC1796

Peripheral Units (Vol. 2 of 2)

General Purpose Timer Array (GPTA)

User’s Manual 24-240 V2.0, 2007-07

GPTA, V2.0

OMG0,

OMG1,

OMG2,

OMG3

[6:4],

[14:12],

[22:20],

[30:28]

rw Multiplexer Group Selection

This bit field determines the OMGng which is

connected to input n of I/O Group g or Output group

g-7.

XX1

OMG1g selected

XX0

OMG2g selected

All other combinations are reserved. If a reserved

combination of OMGn value is selected, the

corresponding OMG output is forced to 0 level.

For compatibility reasons, the values 001

(for

XX1

) and 010

(for XX0

) should be used for

OMGn bit field programming.

0 3, 7, 11,

15, 19,

23, 27,

r Reserved

Read as 0; should be written with 0.

Field Bits Type Description
