TC1796
Peripheral Units (Vol. 2 of 2)
Analog-to-Digital Converter (ADC)
User’s Manual 25-68 V2.0, 2007-07
ADC, V2.0
TCRP
Timer Conversion Request Pending Register
(1B8
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0
r
1514131211109876543210
TRP
15
TRP
14
TRP
13
TRP
12
TRP
11
TRP
10
TRP
9
TRP
8
TRP
7
TRP
6
TRP
5
TRP
4
TRP
3
TRP
2
TRP
1
TRP
0
rh rh rh rh rh rh rh rh rh rh rh rh rh rh rh rh
Field Bits Type Description
TRPn
(n = 0-15)
nrhTimer Conversion Request Pending Flag for
Channel n
A pending flag TRPn is set each time a conversion
request is generated for channel n on timer underflow
that could not be serviced immediately. A start of
conversion of the pending request leads
automatically to a cleared of the pending flag. All
pending request flags can also be cleared under
software control, if bit AP.TP is cleared.
0
B
No timer based conversion request is pending
for channel n
1
B
A timer based conversion request is pending for
channel n
0 [31:16] r Reserved
Read as 0.
