TC1796
Peripheral Units (Vol. 2 of 2)
Analog-to-Digital Converter (ADC)
User’s Manual 25-74 V2.0, 2007-07
ADC, V2.0
EXCRP
External Conversion Request Pending Register
(1BC
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0
r
1514131211109876543210
EX
CRP
15
EX
CRP
14
EX
CRP
13
EX
CRP
12
EX
CRP
11
EX
CRP
10
EX
CRP
9
EX
CRP
8
EX
CRP
7
EX
CRP
6
EX
CRP
5
EX
CRP
4
EX
CRP
3
EX
CRP
2
EX
CRP
1
EX
CRP
0
rh rh rh rh rh rh rh rh rh rh rh rh rh rh rh rh
Field Bits Type Description
EXCRPn
(n = 0-15)
nrhExternal Event Conversion Request Pending Flag
for Channel n
EXCRPn is set each time a conversion request is
generated for channel n by an external event that
could not be serviced immediately. A start of
conversion of the pending request leads automatically
to a clear of the pending flag. All pending request flags
can also be cleared under software control, if bit
AP.EXP is cleared.
0
B
No external event based conversion request is
pending for channel n
1
B
An external event based conversion request is
pending for channel n
0 [31:16] r Reserved
Read as 0.
