Infineon Technologies TC1796 User Manual

TC1796
Peripheral Units (Vol. 2 of 2)
Analog-to-Digital Converter (ADC)
User’s Manual 25-93 V2.0, 2007-07
ADC, V2.0
SW0CRP
Software SW0 Conversion Request Pending Register
(180
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0
r
1514131211109876543210
SW0
CRP
15
SW0
CRP
14
SW0
CRP
13
SW0
CRP
12
SW0
CRP
11
SW0
CRP
10
SW0
CRP
9
SW0
CRP
8
SW0
CRP
7
SW0
CRP
6
SW0
CRP
5
SW0
CRP
4
SW0
CRP
3
SW0
CRP
2
SW0
CRP
1
SW0
CRP
0
rh rh rh rh rh rh rh rh rh rh rh rh rh rh rh rh
Field Bits Type Description
SW0CRPn
(n = 0-15)
nrhSoftware SW0 Conversion Request Pending Flag
for Channel n
A SW0CRPn pending flag is set each time a
conversion request is generated for channel n by
SW0, that could not be serviced immediately. A start
of the conversion for a pending request leads
automatically to a clear of the pending flag. All
pending request flags can also be cleared under
software control, if bit AP.SW0P is cleared.
0
B
No SW0 based conversion request is pending
for channel n.
1
B
A SW0 based conversion request is pending for
channel n.
0 [31:16] r Reserved
Read as 0.
