TC1796
Peripheral Units (Vol. 2 of 2)
Analog-to-Digital Converter (ADC)
User’s Manual 25-95 V2.0, 2007-07
ADC, V2.0
MSS1
Module Service Request Status Register 1
(1D4
H
) Reset Value: 0000 0000
H
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0
r
1514131211109876543210
0
MSR
AS
MSR
QR
MSR
SY
MSR
T
r rwh rwh rwh rwh
Field Bits Type Description
MSRT 0rwhModule Service Request Status for Source Timer
This bit specifies if a timer source service request has
been generated.
0
B
No timer source service request has been
generated.
1
B
A timer source service request has been
generated.
This bit is cleared by writing a 1 to its bit position.
MSRSY 1rwhModule Service Request Status for Source
Synchronized Injection
This bit specifies if a synchronized injection source
service request has been generated.
0
B
No Synchronized Injection source service
request has been generated.
1
B
A Synchronized Injection source service request
has been generated.
This bit is cleared by writing a 1 to its bit position.
MSRQR 2rwhModule Service Request Status for Source Queue
This bit specifies if a queue source service request has
been generated.
0
B
No queue source service request has been
generated.
1
B
A queue source service request has been
generated.
This bit is cleared by writing a 1 to its bit position.
