Analog-to-Digital Converter (ADC)
User’s Manual 25-98 V2.0, 2007-07
ADC, V2.0
PSY [7:5] rw Synchronized Service Request Node Pointer
This bit fields selects which service request output
line will be activated if the synchronized injection
service request becomes active and ENPSY = 1.
000
B
Service request output SR0 is selected.
001
B
Service request output SR1 is selected.
010
B
Service request output SR2 is selected.
011
B
Service request output SR3 is selected.
100
B
Service request output SR4 is selected.
101
B
Service request output SR5 is selected.
110
B
Service request output SR6 is selected.
111
B
Service request output SR7 is selected.
ENPQR 8rwQueue Service Request Enable
This bit enables the generation of a service request
when a queue service request event occurs.
0
B
Queue service request generation is disabled.
1
B
Queue service request generation is enabled.
PQR [11:9] rw Queue Service Request Node Pointer
This bit fields selects which service request output
line will be activated if the queue service request
becomes active and ENPQR = 1.
000
B
Service request output SR0 is selected.
001
B
Service request output SR1 is selected.
010
B
Service request output SR2 is selected.
011
B
Service request output SR3 is selected.
100
B
Service request output SR4 is selected.
101
B
Service request output SR5 is selected.
110
B
Service request output SR6 is selected.
111
B
Service request output SR7 is selected.
ENPAS 12 rw Auto-Scan Service Request Enable
This bit enables the generation of a service request
when an auto-scan service request event occurs.
0
B
Auto-scan service request generation is
disabled.
1
B
Auto-scan service request is enabled.
