TC1796

Peripheral Units (Vol. 2 of 2)

Fast Analog-to-Digital Converter (FADC)

User’s Manual 26-47 V2.0, 2007-07

FADC, V2.0

The Channel x Conversion Result Register RCHx contains the conversion result ADRES

of channel x.

RCHx (x = 0-3)

Channel x Conversion Result Register

(40

+x*4

) Reset Value: 0000 0000

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

1514131211109876543210

0ADRES

rrwh

Field Bits Type Description

ADRES [9:0] rwh AD Conversion Result

This bit field contains the conversion result of

channel x. ADRES can only be overwritten by

software if GCR.RESWEN = 1 (see also register

GCR description on Page 26-38).

0 [31:10] r Reserved

Read as 0; should be written with 0.
